Edison to PowerCon Cables
Designed to illuminate your stage and fill your venue with sound.
The Concert Cables PowerLine offers excellent craftsmanship, name brand parts and components, American Made wire, and is overbuilt to ensure a long life. In addition, each cable comes with a lifetime warranty that covers manufacturing defects. The Edison to PowerCon Cable is offered in both 16 and 14 gauge wire combinations, in lengths varying from 3' (1m) to 100' (33m) in length. Contact us today for pricing information!
Industry Standards
We use industry standard connectors, including a Leviton 5-15P and a Neutrik NAC3FCA connector on every cable. We always use genuine parts, and never parts marked as "Compatible" by other manufacturers.
Common Cabling
The PowerCon Cable has become a staple in the entertainment industry. In many situations requiring locking connectors, manufacturers have chosen Neutrik PowerCon as their input source. Pictured above is the Martin Mac Quantum Profile.
16 Gauge Cables
All cables on this table are Edison to PowerCon, or NEMA 5-15P to Neutrik NAC3FCA Cables.
| Part Number | Wire Length | Wire Gauge | UPC / EAN |
|---|---|---|---|
| ED-PCA-16-18 | 1.5 Feet | 16 AWG (1.31mm) | 684191906794 |
| ED-PCA-16-3 | 3 Feet | 16 AWG (1.31mm) | 684191906725 |
| ED-PCA-16-6 | 6 Feet | 16 AWG (1.31mm) | 684191906732 |
| ED-PCA-16-10 | 10 Feet | 16 AWG (1.31mm) | 684191906572 |
| ED-PCA-16-15 | 15 Feet | 16 AWG (1.31mm) | 684191906800 |
| ED-PCA-16-25 | 25 Feet | 16 AWG (1.31mm) | 684191906770 |
| ED-PCA-16-50 | 50 Feet | 16 AWG (1.31mm) | 684191906787 |
14 Gauge Cables
All cables on this table are Edison to PowerCon, or NEMA 5-15P to Neutrik NAC3FCA Cables.
| Part Number | Wire Length | Wire Gauge | UPC / EAN |
|---|---|---|---|
| ED-PC-14-18 | 1.5 Feet | 14 AWG (1.62mm) | 684191906831 |
| ED-PC-14-3 | 3 Feet | 14 AWG (1.62mm) | 684191906725 |
| ED-PC-14-6 | 6 Feet | 14 AWG (1.62mm) | 684191906732 |
| ED-PC-14-10 | 10 Feet | 14 AWG (1.62mm) | 684191906534 |
| ED-PC-14-15 | 15 Feet | 14 AWG (1.62mm) | 684191906824 |
| ED-PC-14-25 | 25 Feet | 14 AWG (1.62mm) | 684191906749 |
| ED-PC-14-50 | 50 Feet | 14 AWG (1.62mm) | 684191906817 |
